High Speed Paper Bowl Forming Machine
Our Paper Bowl Machine is a fully automatic system designed to produce high-quality paper bowls and food containers for modern food packaging needs. With integrated processes such as sealing, bottom forming, heating, and rim rolling, the machine delivers strong, hygienic, and perfectly shaped bowls suitable for a wide range of food products.
Max Capacity
85 Pcs/Min
Paper Materials
Single/Double PE Coated Paper
Paper Specifications
150-350 GSM
Product Size
N/A
Complete Technical Specifications
| Specification | Value |
|---|---|
| Max Capacity | 85 Pcs/Min |
| Paper Materials | Single/Double PE Coated Paper |
| Paper Specifications | 150-350 GSM |
| Product Size | N/A |
| Cup Top Dia (TD) | 90-140 mm |
| Cup Height (H) | 50-115 mm |
| Cup Bottom Dia (RB) | 60-110 mm |
| Power Supply | 380V50HZ 3Phase |
| General Power | 16 kw |
| Compressed Air | 0.6-0.8MPa, 0.5 m3 /min |
| Weight | 2800 kgs |
| Dimensions | 3100 x 1350 x 1610 mm |
Explore the Abundant Features of 'High Speed Paper Bowl Forming Machine'!
Unleash your productivity. Elevate your manufacturing experience.
Explore Limitless Possibilities with Paper Bowl Machine's Feature Collection
| Feature | Description |
|---|---|
| Intelligent Operating System | PLC based touch-screen control allows real-time monitoring, fault alerts and smooth production management. |
| Strong & Leak-Proof Sealing | Advanced fan-wall sealing and heating systems ensure durable, food-grade bowl construction. |
| Precision & Safety Monitoring | Built-in photo-electric sensors detect paper breaks or errors, preventing material wastage and machine damage. |
| Ideal for Food Packaging | Perfect for soups, noodles, desserts and ready-to-eat food containers. |
Applications
Explore our diverse range of industrial applications
Coffee & Tea Shops
Cafes & Coffee Chains
Takeaway & Drive-Thru
Office & Corporate Events
Street Vendors & Food Stalls
Vending Machines & Convenience Stores
